Blackmagicdesign ATEM Television Studio Pro HD Power Supply Repair Part 4 of 4

The unit is a Blackmagicdesign ATEM Television Studio Pro HD. In the series of 4 video I will show how to solder a Neutrik NC4FX XLR 4-Pin Female Cable Connector to a 12v, 4 amp external power supply. Also I will take you through the trouble shooting and repair of the internal SMPS Switch Mode Power Supply. These videos are not for you TIC TACKERS that have an attention span of a Gnat. Be careful when working with capacitors, they do and will hold a charge. The charge will shock you.



Disclaimer:

I am not a certified Electronic Technician nor do I play one on TV. I have slept at a Holiday Inn Express from time to time. I did work as an electronic technician form 1981 to 1987 repairing home and car audio. I also have a EE degree. I do research on the internet and read the service manuals when possible. I highly recommend anyone working on their own electronic devices to do the same. If you cannot repair the system you are working on, find a qualified technician who can.
